Type: RSC 4/7 Description: Field attachable connector, M12 male connector, straight version, with threaded joint, assembling with screw terminals

Description: Han 3A-STI Gender: male Mechanical working life - mating cycles: >= 500 RoHS conformity: Yes Size: 3 A Series: Han A® Limiting temperature, min.: -40 °C Limiting temperature, max.: 125 °C Termination method: Screw terminal Number of contacts: 3 Rated current: 10 A Rated voltage conductor - ground: 230 V Rated voltage conductor - conductor: 400 V Rated impulse voltage: 4 kV Pollution degree: 3 Contact identification, min.: 1 Contact identification, max.: 3 Wire cross section, min.: 0.75 mm2 Wire cross section, max.: 1.5 mm2 Wire gauge AWG, min.: AWG 18 Wire gauge AWG, max.: AWG 14 Rated current, alternative: 10 A Rated voltage, alternative: 250 V Rated impulse voltage, alternative: 4 kV Pollution degree: 3 Colour, insert: RAL 7032 (light grey) Material, insert: polycarbonate Net Weight: 14.4 g Flammability insert acc. to UL 94: V 0 Flammability seal acc. to UL 94: V 0 Rated voltage acc. to UL: 600 V Approval UL: Yes Approval CSA: Yes Approval GL: Yes Specification: IEC 60664-1//IEC 61984 Series, insert: Han® 3 A Tightening torque: 0.25 Nm Insulation resistance: >= 10 Ohm Exponent: 10 Protective earth conductor (PE): Yes

Versión de producto: 1.3 Homologaciones: CE, cULus Listed, TÜV, FCC, IC Principio sensor: Transpondedor Tipo de encriptado: encriptados Número de salidas OSSD: 2 Número de entradas: 2 Tipo de borne: M12, 8pol. male Tensión alimentación (V): 24,0 Tipo de tensión de alimentación: DC Consumo de energía DC: 2.0 W Distancia de conmutación protegida: 15.0 mm Distancia de desconexión asegurada: 40.0 mm Grado de protección, carcasa: IP67 Dimensión Ancho: 40.0 mm Dimensión de altura: 75.0 mm Dimensión Profundidad: 40.0 mm Peso bruto: 181 g .
